PUMP SPECK DELUXE ECO INVERTER BRONZE
- Brand: BADU
- Product Code: DELUXE ECO VS BRONZE
- Availability: In Stock
-
2,997.08€
- Ex Tax:2,417.00€
230V | 0-24m3/h | 1.4kW
This circulation pump combines the successful construction of the BADU Prime with a synchronously compact power unit to create a
highly efficient power packet with space-saving construction. A built-in control panel and easy to navigate menu provide for
simple management of the motor. Can be controlled using the BADU Eco Logic remote control.<br>
The pump is delivered ready for connection with a 5-wire control cable, cable and plug.
Field of application
Swimming pool water circulation through a filter system. The pump can be installed max. 3 m above or below water level.
Design
Monoblock-type pump with integrated strainer tank. The bellow-type mechanical seal is mounted on a plastic shaft protector sleeve.
Motor/pump shaft has no contact with the pool water providing complete electrical separation.
- Strainer basket PP
- Mechanical seal carbon / ceramic / NBR
- Pool type Naturpool / Schwimmteich
- Filter size in mm 400 – 500
- Strainer basket in mm approx. 3,2 x 2,6
- Strainer capacity in l approx. 3, approx. 3
- Intermediate housing PP TV 40, PP TV 40
- Gland housing PP TV 40, PP TV 40
- Impeller PP GF 30
- Pump casing PP GF 30
- Screws stainless steal
- Class PREMIUM
- Motor performance in kW (P2) 1,40
- Pool size in m³ 30 – 90, 30 – 90
- Flow rate Q in m³/h max. 28
- Total head H in m WS max. 18
- Lid PC, transparent / PA 66 GF 30, PC, transparent / PA 66 GF 30
- Diffuser PA 66 GF 30
